Bauxite powder ultrafine grinding mill is a widely used ultra-fine grinding mill for various minerals powder processing, including bauxite.
Bauxite powder ultrafine grinding mill incorporate advanced technology such as high-speed rotation, air classification to achieve ultrafine particle sizes.
The Bauxite powder ultrafine grinding mill utilizes a multi-stage grinding process to efficiently process bauxite powder.
1. Crushing stage: After the large pieces of material are crushed to the required particle size by the crusher, they are sent to the storage bin by the elevator, and then evenly sent to the grinding cavity of the main machine by the vibrating feeder.
2. Grinding stage: The material enters between the grinding roller and the grinding ring of the main machine. Through the rotation of the grinding roller and the action of centrifugal force, the material is repeatedly crushed and sheared, thereby achieving crushing.
3. Classification stage: The ground powder enters the classifier with the air flow. The powder that meets the fineness requirements passes through the classifier with the air flow and enters the cyclone collector. The powder that is too coarse is returned to the grinding area to continue grinding.
4. Collection stage: The fine powder is collected by the cyclone collector and discharged through the discharge valve, which is the finished product. The dust-containing gas is purified by the bag dust collector and then discharged.
Here are some key features and components of the Bauxite powder ultrafine grinding mill:
1. High Efficiency Classifier: The Bauxite powder ultrafine grinding mill is equipped with a high-efficiency classifier, which ensures the accuracy and fineness of the finished product.
2. Grinding Rollers and Rings: The grinding rollers and rings are made of special materials with high wear resistance, ensuring a long service life and minimal maintenance requirements.
Grinding Chamber: The grinding chamber is designed to minimize energy consumption while maximizing grinding efficiency. It is lined with wear-resistant materials to prolong its lifespan.
3. Main Motor: The Bauxite powder ultrafine grinding mill is powered by a high-performance motor that delivers the necessary power for efficient grinding operations.
4. Control System: The Bauxite powder ultrafine grinding mill often comes with an advanced control system, allowing operators to adjust various parameters such as grinding pressure, grinding speed, and classifier speed to optimize the milling process.
5. Dust Collector System: To maintain a clean working environment and prevent environmental pollution, the mill is typically equipped with a dust collector system to capture and remove fine particles generated during the grinding process.
6. Safety Features: Safety features such as overload protection and emergency stop mechanisms are often integrated into the design to ensure safe operation.
Bauxite powder refers to finely ground bauxite ore that has been processed into a fine powder form. It is typically produced by crushing and grinding raw bauxite ore into a fine particle size to facilitate its use in various applications.
Bauxite powder Uses
Bauxite powder has various industrial applications due to its aluminum content and other properties. Some common uses include:
1. Refractory applications: Bauxite powder is used as a raw material in the production of refractory bricks, castables, and other refractory products due to its high aluminum content and heat-resistant properties.
2. Abrasives: Bauxite powder is used as an abrasive material in the manufacturing of abrasives such as grinding wheels, sandpaper, and polishing compounds.
3. Welding fluxes: Bauxite powder is sometimes used as a fluxing agent in welding applications to help remove impurities and improve the weld quality.
4. Filler material: Bauxite powder can be used as a filler material in various industries such as plastics, rubber, and ceramics to enhance product properties and reduce costs.
When choosing a Bauxite powder ultrafine grinding mill, factors such as production capacity, required fineness, energy consumption, and equipment price need to be considered. It is very important to choose the right grinding machine according to your specific requirement s.
Our company has various models of HGM series Bauxite powder ultrafine grinding mill for you to choose from.
| Model | HGM80 | HGM80A | HGM90L | HGM100L-Ⅱ | HGM100P | HGM125L | HGM1680L |
| Ring Diameter(mm) | 800 | 800 | 900 | 1000 | 1000 | 1250 | 1680 |
| Ring Number (PCS) | 3 | 3 | 4 | 4 | 4 | 4 | 4 |
| Input Size (mm) | ≤10 | ≤10 | ≤10 | ≤15 | ≤15 | ≤20 | ≤20 |
| Adjustable range of finished product (mesh) | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 | 150-3000 |
| Capacity (t/h) | 0.5-5.5 | 0.5-5.5 | 0.8-6.5 | 1.2-10 | 1.2-11 | 2.5-20 | 5-45 |
| Outlet Size L*W*H (mm) | 8605*4139*6050 | 10454*3393*6626 | 11735*3952*7525 | 14507*3633*7562 | 14362*4200*7562 | 19261*4406*8591 | 25067*5414*9007 |
| Main motor power (kw) | 75 | 75 | 55*2 | 132/75*2 | 132/75*2 | 185 | 315 |
| Unit kw | HGM80 | HGM90L | HGM100L-Ⅱ | HGM100P | HGM125L | HGM1680L |
| Main unit | 75 | 2*45 | 132-150 | 132-150 | 185-200 | 315 |
| Classifier | 18.5 | 18.5-30 | 30-37 | 30-37 | 75 | 132 |
| Blower | 45 | 55 | 75 | 75 | 2*45-2*55 | 2*75-2*90 |
| Crusher | 18.5 | 18.5 | 18.5 | 18.5 | 45 | 75 |
| Bucket Elevator | 3 | 3 | 4 | 4 | 4 | 7.5 |
| Belt Conveyor Feeder | 1.5 | 1.5 | 1.5 | 1.5 | 1.5 | 2 |
| Discharging Valve | 2*0.75 | 1.1 | 1.1 | 1.1 | 1.5 | 2*1.5 |
| Air Compressor | 11 | 15 | 22 | 22 | 37 | 55 |
Bauxite powder ultrafine grinding mill are suitable for processing non-flammable and explosive mineral materials with a hardness of no more than 6 and a humidity of less than 6%, such as:
1. Montmorillonite: improve its adsorption capacity and surface activity, used in oil field drilling, cosmetics, medicine and other fields.
2. Kaolin: Ultrafine powder is used in papermaking, ceramics, rubber and other industries.
3. Talc: fine powder is widely used in cosmetics, plastics, coatings and other industries.
4. Limestone: Ultrafine powder is used in flue gas desulfurization, building materials, chemical industry and other fields.
5. Calcium Carbonate: Ultrafine powder is used in papermaking, building materials, chemical industry and other fields.
